CYT1000AEG single segment LED linear constant current control chip

CYT1000AEG is a linear constant current IC with adjustable outputcurrent, high constant-current accuracy, simple application scheme, Cost andResistance capacitance step-down are comparable, with over-...

Model:

CYT1000AEG

Brand: CYT1000AEG

Price Indication: 1.1 Stock: 9999999999

Product Description:

CYT1000AEG is a linear constant current IC with adjustable outputcurrent, high constant-current accuracy, simple application scheme, Cost andResistance capacitance step-down are comparable, with over-temperatureprotection function, safer and more reliable.

5mA to 60mA adjustable output current,

accuracy of constant current can reach ±5%

With over-temperature protection function

No EMI problem

Chip and LED share aluminum substrate

Simple circuit, cost-effective

Package: ESOP8

產品型號	最大電流	恒流精度	通道	OTP溫度	MOS管	MOS電壓	封裝
CYT1000AE	60mA	±5%	1	120℃	內置	500V	ESOP-8
CYT1000AEG	60mA	±5%	1	140℃	內置	500V	ESOP-8
CYT1000A	120mA	±5%	2	120℃	內置	500V	ESOP-8
CYT1000AG	120mA	±5%	2	140℃	內置	500V	ESOP-8
CYT1000B	60mA	±5%	1	120℃	內置	500V	TO252-2
CYT1000BG	60mA	±5%	1	140℃	內置	500V	TO252-2
CYT1000DE	60mA	±5%	1	140℃	內置	500V	SOT89-3
CYT1000AH	80mA	±3%	1	150℃	內置	700V	ESOP-8
CYT1000AGH	120mA	±5%	2	140℃	內置	700V	ESOP-8
CYT1000BH	80mA	±4%	1	150℃	內置	700V	TO252-2
CYT1000DH	80mA	±4%	1	150℃	內置	700V	SOT89-3
CYT1010BS	120mA	±5%	1	140℃	內置	500V	TO252-2
CYT16G	60mA	±5%	1	140℃	內置	500V	SOT23-3
CYT1002AEG	100mA	±5%	1	140℃	內置	700V	ESOP-8
CYT1012BS	120mA	±5%	1	150℃	內置	700V	TO252-2
CYT1012BM	185mA	±5%	1	150℃	內置	700V	TO252-2
CYT1005AEG	45mA	±5%	1	130℃	內置	500V	ESOP-8
CYT1005AG	90mA	±5%	2	130℃	內置	500V	ESSOP-10
CYT1004AEG	45mA	±5%	1	160℃	內置	500V	ESOP-8
CYT3000BM	100mA	±5%	3	145℃	內置	700V	ESOP-8
CYT3000E	100mA	±5%	4	145℃	內置	700V	ESOP-8
CYT3012B	100mA	±5%	5	140℃	內置	700V	ESOP-16
CYT8011TG	60mA	±3%	2	140℃	內置	500V	ESOP-8
CYT8000C	60mA	±3%	2	150℃	內置	500V	ESOP-8
CYT8000D	100mA	±3%	2	150℃	內置	500V	ESOP-8
CYT101D	30mA	±3%	1	150℃	內置	90V	SOT23-3
